Abysm Oceanic Tide 360 Triple Liquid Cooling with ARGB Lighting
In the ever-evolving world of PC gaming and high-performance computing, effective cooling solutions are paramount. The ABYSM OCEANIC TIDE 360 stands out as a powerful all-in-one liquid cooling solution, offering a blend of aesthetics and performance that appeals to enthusiasts and casual users alike. This review delves into its specifications, design, installation process, and performance metrics to provide a comprehensive understanding of what this cooler brings to the table.
Technical specifications of the ABYSM OCEANIC TIDE 360
| Model: ABYSM OCEANIC TIDE 360 | |
| Compatibility | Intel LGA 1851 / 1700 / 1200 / 115x / 2066 / 2011 AMD AMx / FMx Supports a maximum TDP of 300W |
| Radiator | Aluminum fins Dimensions: 397 x 129 x 27 mm |
| Block | Copper base ARGB LED lighting |
| Pump | 2,500 RPM (± 10%) Flow rate: 1.15 kg/min Noise level: < 30 dBA |
| Tubes | Rubber with braiding Length: 380 mm Thickness: 3.4 mm |
| Fans | Three fans of 120 x 120 x 25 mm Speed: 800 - 1800 RPM Noise level: 23.8 – 35.4 dBA FDB bearings ARGB LED lighting Durability: 50,000 hours (MTBF) |
| Extras | Includes thermal paste syringe |
Packaging and accessories
The unboxing experience of the ABYSM OCEANIC TIDE 360 begins with its sleek packaging. The elongated cardboard box displays the product's design prominently on the front, highlighting its main features on one side and compatibility specifications on the back.
Inside, a protective cardboard frame organizes and secures all components of the liquid cooling system. Each part is carefully placed to prevent damage during transport.
Documentation is neatly packaged in an envelope, while a plastic bag contains the mounting kit, designed for broad compatibility with modern sockets. Specifically, it supports:
- AMD: AMx and FMx
- Intel: LGA 1851 / 1700 / 1200 / 115x / 2066 / 2011
This compatibility ensures that the cooler can be used in virtually any modern PC build.
Design of the ABYSM OCEANIC TIDE 360
Once unboxed, the ABYSM OCEANIC TIDE 360 presents itself as a robust all-in-one cooling unit. Its overall design is conventional yet features distinctive elements that enhance its visual appeal.
Three 120mm fans
Mounted on the radiator, the cooler features three 120 x 120 x 25 mm fans. These fans, designed with nine translucent blades, effectively showcase the ARGB LED lighting emanating from the central rotor. With a speed range of 800 - 1800 RPM and a noise level of 23.8 to 35.4 dBA, they are equipped with FDB bearings that promise durability and reliable performance.
Triple 360 mm radiator
The cooling system includes a triple radiator made of aluminum with dimensions of 397 x 129 x 27 mm. The standard thickness allows for substantial cooling capabilities while maintaining a low profile suitable for most cases.
Braided rubber tubes
Two rubber tubes extend from the radiator, measuring 380 mm in length and 3.4 mm in thickness. The braided design not only enhances aesthetics but also provides flexibility in routing for optimal placement.
Reservoir with ARGB lighting and copper base
One of the most striking design elements of the ABYSM OCEANIC TIDE 360 is its reservoir. The black plastic surface features a textured brick pattern, allowing the ARGB LED lighting to shine through the translucent sections. Internally, the pump operates at 2,500 RPM, moving a flow rate of 1.15 kg/min with minimal noise, making it suitable for quiet environments.
On the opposite side, a large copper base ensures compatibility with processors up to 300W TDP, further enhancing its versatility across various builds.
Installation and mounting process
The installation of the ABYSM OCEANIC TIDE 360 is straightforward, especially when working with a processor on the LGA 1851 socket. The backplate is affixed behind the motherboard, utilizing adhesive strips that provide a secure hold while allowing for easy placement.
After applying thermal paste to the processor, the block can be positioned and secured with four corner screws. This process is generally uncomplicated, although using the adhesive strips multiple times can complicate the mounting process.
Once installed and powered on, the cooler creates a stunning visual display, with ARGB lighting radiating through the reservoir and fan blades, adding a vibrant aesthetic to any build.
Testing methodology and setup
For the review of the ABYSM OCEANIC TIDE 360, the following test setup was utilized:
- Chassis: Thermaltake Core P3 TG Pro
- Motherboard: MSI MEG Z890 ACE
- Processor: Intel Core Ultra 9 285K
- RAM: Kingston Fury Renegade DDR5 CUDIMM 8,800 MHz
- Graphics Card: Nvidia GeForce RTX 5090 Founders Edition
- Power Supply: be quiet! Dark Power 13 - 1000 W
- Operating System: Windows 11 Pro
To assess the cooling performance, a stress test was conducted using Aida64, where the processor was warmed up for five minutes to stabilize its temperature before recording the average temperature over the next minute. This method provides a clear understanding of the cooler's efficiency.
Performance testing of the ABYSM OCEANIC TIDE 360
With an ambient temperature of 25 ºC, the ABYSM OCEANIC TIDE 360 managed to keep the processor at around 38 ºC during idle conditions, with the fans spinning at low speeds and producing minimal noise.
During the stress test, the processor temperature reached approximately 80 ºC, with the fans ramping up to high speeds, generating a noise level of 50.5 dBA. Given that the Intel Core Ultra 9 285K has a TDP of 250W, these thermal readings are impressive, placing it comfortably in the mid-range of our performance ranking.
Pricing and availability
The ABYSM OCEANIC TIDE 360 is competitively priced at €72, making it an attractive option for those looking for performance without breaking the bank. Its feature set in a crowded market of alternatives makes it a standout choice.
| Main Advantages | |
| + | Excellent performance for high TDP processors |
| + | Very controlled noise levels at maximum RPM |
| + | Compatible with all modern domestic sockets |
| Negative Aspects | |
| - | The backplate can only be adhered once, complicating reinstallation in a second PC |
In conclusion, the ABYSM OCEANIC TIDE 360 impresses with its combination of aesthetics, performance, and competitive pricing, making it a worthy investment for any PC builder looking to enhance their system's cooling capabilities.
