MSI MPG Velox 300R Airflow PZ aggressive mid tower with ARGB fans
Today, we dive into an in-depth review of the MSI MPG VELOX 300R AIRFLOW PZ, a semi-tower chassis that stands out with its modern design and striking aesthetics. With a mesh front panel and a tempered glass side, this case not only promises excellent airflow but also enhances the visual appeal of any gaming setup. Accompanied by two 160mm ARGB front fans, it’s built for both performance and style. Let’s explore its features and specifications in detail.
Technical specifications of the MSI MPG VELOX 300R AIRFLOW PZ
| MSI MPG VELOX 300R AIRFLOW PZ | |
| Form Factor | Semi-tower with a mesh front and tempered glass side Compatible with E-ATX, ATX (BTF), micro-ATX, and mini-ITX motherboards |
| Dimensions | 485 x 235 x 518 mm (H x L x W) |
| Drive Bays | 1 x 3.5/2.5 inches 1 x 3.5 inches 4 x 2.5 inches |
| Cooling | Front: 3 x 120 / 140 mm | 2 x 160 mm (included ARGB) Side: 3 x 120/ 140 mm Top: 3 x 120 / 2 x 140 mm Rear: 1 x 120 mm (included) Power supply shroud: 2 x 120 mm Bottom: 120 mm |
| Compatible Radiators | Front: 360 / 280 / 240 / 140 / 120 mm Top: 360 / 280 / 240 / 140 / 120 mm Side: 360 / 280 / 240 / 140 / 120 mm Rear: 120 mm |
| Expansion Slots | 7 horizontal slots |
| Connectors | 1 x USB-C 3.2 Gen2x2 (20 Gbps) 2 x USB 3.0 (5 Gbps) 2 x TRS 3.5 mm jacks (headphones and microphone) |
| Capacity | Cooler up to 165 mm Graphics cards up to 400 mm ATX power supply up to 200 mm |
| Other | Pre-installed GPU support |
Packaging and Accessories
The MSI MPG VELOX 300R AIRFLOW PZ comes in a sturdy cardboard box designed to protect it during transit. Inside, the chassis is held securely in place with two black polystyrene frames, ensuring it remains undamaged, complemented by a plastic bag to shield it from dust.
Along with the chassis, you’ll find documentation, a reflective sticker, and a comprehensive screw kit for installing all components. The package also includes plastic zip ties for cable management and a versatile Velcro tie, as well as spare clips for the quick-release of side covers.
MSI MPG VELOX 300R AIRFLOW PZ – Exterior Design
The exterior of the MSI MPG VELOX 300R AIRFLOW PZ is crafted from durable steel, weighing in at 9.7 kg. It features a modern and aggressive design available in both black and white finishes. With dimensions of 485 x 235 x 518 mm, it sits comfortably within the semi-tower category.
Mesh Front Panel with Dual ARGB Fans
The chassis boasts a mesh front panel that facilitates excellent airflow towards internal components, supported by two striking 160 mm front fans. These fans come with dual-blade designs and ARGB lighting, adding a splash of color to your setup. Accessing these fans is straightforward—simply remove the steel frame and the magnetic dust filter for easy maintenance.
Tempered Glass Side Panel
As is common in modern chassis, the MSI MPG VELOX 300R AIRFLOW PZ features a tinted tempered glass side panel. This allows for a glimpse into the internal components, showcasing your setup and any RGB lighting.
The opposite side features a metal panel with large perforations, promoting airflow from potential side fans and additional components behind the motherboard.
Rear Panel Layout
The rear of the MSI MPG VELOX 300R AIRFLOW PZ follows a conventional scheme. The power supply is positioned at the bottom, with space for seven expansion slots above it. However, the design does not allow for vertical GPU installation, which may disappoint some users. There is also a 120 mm fan slot at the back, occupied by a non-illuminated unit.
Top Panel Airflow Design
Flipping the chassis reveals a top panel that features a mesh design, maximizing the surface area for airflow from potential top-mounted fans.
Connectors and I/O Ports
The right side, from a frontal perspective, houses connectivity options and buttons. This includes a USB-C 3.2 Gen2x2 port capable of up to 20 Gbps, along with two USB 3.0 ports (5 Gbps) and a combined TRS 3.5 mm jack for headphones and microphones. In addition to the power button, there is a switch that allows users to cycle through various LED lighting modes, which may also function to reset the computer.
On the opposite side, the entire bottom area is covered by a removable dust filter, though accessing it while the chassis is positioned on a desk can be cumbersome.
MSI MPG VELOX 300R AIRFLOW PZ – Interior Design
Once the side and front panels are removed, we gain full access to the interior of the MSI MPG VELOX 300R AIRFLOW PZ. This model accommodates E-ATX, ATX (BTF), micro-ATX, or mini-ITX motherboards, although BTF micro-ATX boards are not supported. A cooler up to 165 mm in height and graphics cards up to 400 mm in length can be installed, ensuring ample space for high-performance components.
Pre-installed ARGB Front Fans
One noteworthy feature is the inclusion of two 160 mm ARGB fans pre-installed in the front. These fans can be configured at three speed levels without software, offering flexibility. Users can also replace these fans with up to three 120 mm or 140 mm units, or even install a triple 360 mm radiator in this area.
Top Radiator Support
Under the top panel, there is space for a triple 360 mm radiator or a dual 280/240 mm radiator, combined with either 120 mm or 140 mm fans. This allows for extensive cooling options, catering to various configurations.
Rear Fan and GPU Installation Insights
The rear fan mirrors the design of the front units but lacks LED lighting. Unfortunately, the inability to mount the GPU vertically is a drawback for a chassis in this price range. However, the chassis provides ample cable management space behind the motherboard tray and supports up to four 2.5-inch drives or one 3.5-inch drive, occupying two of the slots.
Power Supply and Cable Management
At the bottom, users can install an ATX power supply with a maximum depth of 200 mm, which sits on foam strips to minimize vibration. This attention to detail in design extends to a controller for fan speed and lighting located in the upper section of the chassis, allowing for additional ARGB fan or LED strip connections.
The cable management system includes headers for USB connections, audio connectors, two-pin cables for the power button, and a SATA connector to power the fan controller.
Price and Availability
The MSI MPG VELOX 300R AIRFLOW PZ is available on the official MSI website for 149 euros, with both black and white color options priced the same. While it is not the cheapest option, the robust build quality and spacious internal layout make it a worthy investment.
Pros and Cons of the MSI MPG VELOX 300R AIRFLOW PZ
Advantages
- High-quality materials and finishes
- Excellent airflow due to its mesh front panel and dual 160 mm fans
- Tinted tempered glass side panel for showcasing components
- Supports up to three radiators (360 / 280 mm)
- Compatible with coolers up to 165 mm in height
- Accommodates graphics cards up to 400 mm in length
- Features USB-C 3.2 Gen2x2 (20 Gbps) and two USB 3.0 ports (5 Gbps)
- Includes hub for PWM fans and ARGB connections
Disadvantages
- Somewhat high price
- Does not allow for vertical GPU installation
In the end, the MSI MPG VELOX 300R AIRFLOW PZ stands out as a premium option for gamers and PC builders alike, marrying functionality with a striking visual appeal.
